Download

Xpedition Layout Browser-Linux

Man sitting behind monitors
Free download of the Xpedition Layout Browser for view and share of Xpedition PCB Layout Designs and schematic cross-probe to Xpedition.

What is the Xpedition Layout Browser?

  • Free download!

  • No time limit

  • Reads PCB Designs from all Xpedition releases

  • File size: 907 MB download, ~2.5 GB installed

  • Current version: Xpedition VX.2.13 (March 2023)

What can you do with the Xpedition Layout Browser?

  • Open any Xpedition Layout database

  • The Xpedition Layout Browser is used to view PCB Layout Designs and schematic cross-probe to Xpedition.

  • Share designs with colleagues who don't have Xpedition installed on their PC’s

  • Review placement and routing

What do I need?

  • Linux Platforms:

    • Linux SUSE 12.5

    • Linux SUSE 15.1

    • Linux SUSE 15.2

    • Linux SUSE 15.3

    • Linux SUSE 15.4

    • Linux RHEL 8.4 x64

    • Linux RHEL 8.5 x64

    • Linux RHEL 8.6 x64

    • Linux RHEL 8.7 x64
