Getting started with schematic analysis for PCB design flow

Detecting critical design errors and eliminating design re-spins caused by schematic errors is critical and can be done by automating the process of board-level verification. HyperLynx Schematic Analysis provides the confidence that your design intent is implemented right the first time, regardless of the PCB design tools used.

In this video, you will learn:

• Advantages of schematic analysis
• The design validation challenge
• Common issues found in manual schematic review
• HyperLynx Schematic Analysis - solution to enable first-pass success
• Key features of HyperLynx Schematic Analysis
• How HyperLynx left-shifts your design flow
