fact sheet

Calibre DESIGNrev

Chip Finishing Platform

The Calibre DESIGNrev platform loads and displays the largest layouts on a typical engineering workstation in seconds. Incremental loading capability provides a scalable solution that is less dependent on I/O, and more efficient for multi-site collaboration.

Rapid rendering delivers rapid zoom/pan visibility. Set individual layer characteristics for customized viewing needs.

  • Enable/disable individual layer visibility.

  • Enable/disable individual layer selectibility.

  • Set custom layer color, fill pattern, and line width.

  • Sort layer list by name, context, and other options.
